Stainless Steel Hot Air Drying Oven 220V/50Hz With Accurate Temperature Control

Stainless Steel Hot Air Drying Oven 220V/50Hz With Accurate Temperature Control
Features Gallery Product Description Request A Quote
Accessories: Stainless Steel Tray
Chamber Size: 400*400*400mm
Control System: Digital Display
Heating Source: Electricity
Material: Stainless Steel
Power: 2.0KW
Product Name: Hot Air Drying Oven
Safety Protection: Over Temperature Protection
Temperature Accuracy: ±1℃
Temperature Range: 50-300℃
Temperature Uniformity: ±2℃
Timing Range: 1-9999min
Voltage: 220V/50Hz
Warranty: 1 Year
High Light:

Stainless Steel Hot Air Drying Oven


220V Hot Air Dry Oven


Dry Hot Air Oven 50Hz

Basic Infomation
Place of Origin: Guangdong
Brand Name: Pootab
Model Number: PT-2010
Payment & Shipping Terms
Packaging Details: Negotialble
Payment Terms: Negotialble
Product Description

Product Description:

The PT-2010 Precision Oven is a high-quality and reliable oven designed for drying, baking, and preheating various materials or samples. It employs a hot air circulation system to ensure uniform temperature distribution within the chamber.



  • Innovative streamlined arc design, with a cold-rolled steel plate housing and electrostatic powder coating.
  • The temperature control system utilizes microcomputer single-chip technology, providing temperature control, timing, and over-temperature alarm functions.
  • Reasonable air duct and circulation system ensure minimal temperature variation within the chamber.
  • Equipped with an intelligent digital temperature control display, providing accurate and intuitive readings. The performance is superior, with parameter adjustment through keypad operation.
  • The temperature control sensor adopts imported capacitive components.
  • Timer and timing functions are available.
  • The interior chamber is made of mirror-finished stainless steel, with easy-to-clean semi-circular corners.
  • The height and number of shelves within the chamber can be adjusted according to user requirements.
  • Equipped with a motor and fan for gentle air circulation, eliminating concerns about blowing away small or powdery items.
  • The door is fitted with a large viewing angle insulated tempered glass for easy observation. The use of nanomaterial door seals and insulation materials enhances overall performance.

Technical Parameters:

Model PT-2010A PT-2010B
Internal Dimensions (W×D×H) 40×40×45 cm 50×50×60 cm
External Dimensions (W×D×H) 62×52×91 cm 67×62×111 cm
Temperature Range Ambient +5℃ to 200℃
Control Mode P.I.D. Automatic Temperature Calculation
Temperature Resolution 0.1℃
Temperature Sensor PT100, Class A
Control Accuracy ±0.3 ℃
Distribution Accuracy ±1%(1℃) at - room100℃
Time Control 0~999.9 hours (minutes) with TIMER and HOLD switches
Standard Accessories Adjustable shelves (2 pieces), observation window (no observation window above 200℃)
Heating Method Hot air circulation
Safety Protection Independent EGO over-temperature power-off, safety overload switch
Manufacturing Material Internal: SUS#304 stainless steel plate, External: baked enamel coating
Power Supply 1PH, AC220V, 50/60Hz, 10A


Classic Taiwanese design with electrical components placed at the bottom to avoid aging due to high temperatures, prolonging the lifespan.
Adjustable door closure tightness with a molded silicone rubber door seal, ensuring a tight seal.
Thickened insulation layer for high-temperature safety.

Control and Execution System:

Intelligent digital temperature control instrument for temperature regulation.
Pt100 platinum resistance temperature sensor for temperature measurement.


Protection System:

Over-temperature protection and alarm device for comprehensive machine protection.
Ensures the integrity of executing components and test samples.


Cabinet Structure:

Classic Taiwanese design. Electrical components are placed below to avoid high-temperature aging and prolong the service life.
The tightness of the door closure can be adjusted. The door seal is made of integrated silicone rubber, ensuring the internal height of the cabinet.
Thickened insulation layer ensures high-temperature safety.



What is the temperature range of the PT-2010 Precision Oven?
The temperature range is from ambient +5℃ to 200℃.

What is the control accuracy of the oven?
The control accuracy is ±0.3℃.

Can I adjust the shelves inside the working chamber?
Yes, the shelves are adjustable in terms of height and quantity according to user requirements.

Does the oven have a timer function?
Yes, it has a time control feature with a range of 0 to 999.9 hours (or minutes).

What safety features are included in the oven?
The oven is equipped with an independent EGO over-temperature power-off system and a safety overload switch.
